YMJ-QM-410 roller type of automatic rotary die cu

Details and Introduction1. HY-QM series rotary die cutting machine is the latest product of our company by introducing advanced foreign technology . 2. It adopts the double roller pressing, once complete the slitting, slotting and punching ,creasing and folding of the corrugated cardboard in high , medium and low grade. It is suitable for the manufacturing of colorful cartons, boxed and other package products of abnormal shape. 3. The main machine adopts electrical ,ray and pneumatic united control system , saving energy, safe and high efficiency.Specifications1.The feeding unit adopt vacuum suction lead edge feeding system, increase the feeding speed and decrease the rate of cardboard blocking when using back-kick feeding system. 2.High pressure centrifugal fans auxiliary feed the cardboard to ensure the The absorption force can be adjustable to different cardboard thickness and dimension. 3.Frequency converter control the force, make sure the smoothly feeding .Ultra-thin feeding function, Even 2mm thickness cardboard can be used. 4. Front bar is adjusted manually . Right bar is electrically adjusted. Left bar own the function of pneumatic flapping. Adjusting of the back bar ( left ,right,up and down) is manual, convenient , fast and precise. 5. PLC control, unite control panel on control desk, simple and clear , convenient and swift. The main motor apply the frequency converter controling the speed, start smoothly and adjust the speed according the user. 6. Equipped with the number counter , easy and clear for production. Start with the alarm bell ring, more safety. 7. The wall panel applies supper quality Cast Iron , 50mm thickness, down feeding roller is made by high quality steel with balance alignment and hard chrome plated. 8. Upper feeding roller is covered by wearable rubber , long life span. Flexible channel on the surface of the rubber roller, ensuring the precise of feeding without damage the cardboard. 9. Die cutting roller is objected to balance alignment and hard chrome plate.Supper quality steel. 10. With compensating gear device in phase adjusting, digital display and control with adjusting in 360 degree both running and stop.11. When feeding ,die cutting roller pneumatic up and touch the rubber roller ; when stop , it automatic down and separate with the rubber roller, saving using time of the rubber roller.12. The rubber applies Taiwan Youli polyurethane rubber, smooth cutting, and easy installation , can be used for 8000,000 times. Mechanical left and right moving device(40mm) for rubber roller: each cutting in different place, prolong the using life of the rubber roller effectively. 13. Speed automatic compensating device make sure that all the boxes are the same size.The soft roller self-repairing device raising the rate of reuse.14. All the transmission gears are helical tooth, smooth transmission , little noise, with the materials of supper quality carbon structural steel,after heating treatment and high frequency hardening , HRC45-50, high wearable and long lifespan. 15. Spray lubrication system , simple and effective.Technological parameter(can do the size according customer special requirement) Name of parameterUnitSpecificationMaximum speedPieces/min140Max paperboardmm1400*1700Valid grinder slicing sizemm1350*1650Thickness of paperboardmm2-11General powerkw7.5DimensionmmL*W*H(3400*1500*1850)WeightTon3.5
